| Place of Origin: | CHINA |
|---|---|
| Brand Name: | TENGDA |
| Certification: | CE,ISO |
| Model Number: | G PW-350C |
| Minimum Order Quantity: | 1 set |
| Price: | ¥130000-20000 / set |
| Packaging Details: | wooden cases |
| Delivery Time: | 30 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50 set per month |
| Material: | Stainless Steel | Color: | Silver |
|---|---|---|---|
| Speed: | 100-150 Bags/min | Machine Weight: | About 1160Kg |
| Machine Size: | (L)4200×(W)960×(H)1520mm | ||
| High Light: | pharmaceutical packaging machines,medicine packaging machine |
||
stainless steel medical high speed pillow packing machine Automatic blanking special for suppository
correlating parameter
|
The machine type
|
GPW-350 |
|
Film Width
|
Max.350mm |
|
Bag length
|
100~200mm |
|
Product Height
|
10~50mm |
|
film diameter
|
Max.400mm |
|
Packing speed
|
5~150package/minute
|
|
power
|
220V50/60Hz3.2Kw |
|
Machine size
|
(L)4200×(W)960×(H)1520mm |
|
machine weight
|
About 1160Kg |
|
Air Pressure
|
≥0.2 MPa |
feature:
1. Can accommodate different size of the package material, change the size and convenience.
2. Frequency control with fast dynamic follow-up performance and high speed accuracy, automatically correct the frequency, in order to achieve the load changes when the motor speed stability. The length of the bag that is set to cut, no need to adjust the empty walk. When a fault occurs, the device alarms and the display shows the corresponding message and the device stops operating.
3. Double synchronous belt pull film, controlled by the cylinder tension, automatic correction, automatic alarm protection, minimize loss
4. Sliding sealing mechanism, can be adjusted sealing (including horizontal and vertical seal) center height and width, fixed and reliable, to ensure long-term operation without displacement. Horizontal, vertical sealing speed continuously adjustable. Sealing width can be produced according to user needs.
