| Place of Origin: | CHINA |
|---|---|
| Brand Name: | TENGDA |
| Certification: | CE,ISO |
| Model Number: | G PW-350C |
| Minimum Order Quantity: | 1 set |
| Price: | ¥130000-200000 / set |
| Packaging Details: | wooden cases |
| Delivery Time: | 30 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50 set per month |
| Material: | Stainless Steel | Color: | Silver |
|---|---|---|---|
| Speed: | 100-150 Bags/min | Machine Weight: | About 1160Kg |
| Machine Size: | (L)4200×(W)960×(H)1520mm | Delivery: | Thirty Days |
| High Light: | pill blister packaging machine,pharmaceutical packaging machines |
||
stainless steel medical high speed pillow packing machine special for Medical Disposable rubber gloves
Pillow packaging machine is a packaging capacity is very strong, and can be used for a variety of specifications for food and non-food packaging, continuous packaging machine. It can be used not only for packaging of non-trademarked packaging materials but also for high-speed packaging using web materials preprinted with a logo. In the packaging production, due to the error of the positioning color code printed on the packaging material, the stretching of the packaging material and the influence of the mechanical transmission and so on, the predetermined sealing and cutting position on the packaging material may deviate from the correct position, resulting in errors. In order to eliminate the error and achieve the purpose of correct sealing, packaging design must consider the automatic positioning problem, to solve this problem are mostly based on the positioning of packaging materials to complete a continuous photoelectric automatic positioning system design. The continuous photoelectric positioning system according to the error compensation work is divided into retractable, brake and two transmission system synchronous.
correlating parameter
|
The machine type
|
GPW-350 |
|
Film Width
|
Max.350mm |
|
Bag length
|
100~200mm |
|
Product Height
|
10~50mm |
|
film diameter
|
Max.400mm |
|
Packing speed
|
5~150package/minute
|
|
power
|
220V50/60Hz3.2Kw |
|
Machine size
|
(L)4200×(W)960×(H)1520mm |
|
machine weight
|
About 1160Kg |
|
Air Pressure
|
≥0.2 MPa |
scope of application
Medical equipment, pharmaceutical packaging.(medicine, cotton swabs, medical syringe, surgical masks, etc.The plastic film mainly used for coiling is used to package different type of multifunctional articles. It is designed for solid packing and suitable for packing all kinds of solid and regular objects. Here we use the bag - wrap - sealing and cutting of packaging machinery, it can be used to packing block, with a tray of solid granular products, the bag for pillow. The main packaging process includes film supply, feeding, wrapping, sealing, cutting and so on.
