| Place of Origin: | CHINA |
|---|---|
| Brand Name: | TENGDA |
| Certification: | CE,ISO |
| Model Number: | G PW-350C |
| Minimum Order Quantity: | 1 set |
| Price: | ¥130000-200000 / set |
| Packaging Details: | wooden cases |
| Delivery Time: | 30 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50 set per month |
| Material: | Stainless Steel | Color: | Silver |
|---|---|---|---|
| Speed: | 100-150 Bags/min | Machine Weight: | About 1160Kg |
| Machine Size: | (L)4200×(W)960×(H)1520mm | Delivery: | Thirty Days |
| High Light: | pill blister packaging machine,pharmaceutical packaging machines |
||
Reciprocating pillow type packing machine silver stainless steel special for Medical adhesive tape
scope of application
Medical equipment, pharmaceutical packaging.(medicine, cotton swabs, medical syringe, surgical masks, etc.The plastic film mainly used for coiling is used to package different type of multifunctional articles. It is designed for solid packing and suitable for packing all kinds of solid and regular objects. Here we use the bag - wrap - sealing and cutting of packaging machinery, it can be used to packing block, with a tray of solid granular products, the bag for pillow. The main packaging process includes film supply, feeding, wrapping, sealing, cutting and so on.
correlating parameter
|
The machine type
|
GPW-350 |
|
Film Width
|
Max.350mm |
|
Bag length
|
100~200mm |
|
Product Height
|
10~50mm |
|
film diameter
|
Max.400mm |
|
Packing speed
|
5~150package/minute
|
|
power
|
220V50/60Hz3.2Kw |
|
Machine size
|
(L)4200×(W)960×(H)1520mm |
|
machine weight
|
About 1160Kg |
|
Air Pressure
|
≥0.2 MPa |
advantage:
1. The main control of the machine adopts programmable controller, the whole machine runs accurately, stably and reliably.
2. The man-machine interface is displayed in English and Chinese, and the setting and storage are convenient and quick.
3. The main motor is equipped with high quality AC frequency converter to realize stepless speed regulation.High precision photoelectric detection and tracking, two-way automatic compensation, accurate and reliable.
5. The device is convenient and sensitive for conveying chain without stopping adjustment.
6. Gravity center type automatic feeder, wide adjustment range, strong applicability, simple and stable.
7.The adjustable end sealing structure makes the sealing more perfect and eliminates the phenomenon of cutting packets.
8. The drive system is simple, more reliable and more convenient to maintain.
