Packging Film Widh: | 5-230Bags/min | Material: | 304 Stainless Steel |
---|---|---|---|
Machine Model: | PW-300E | Delivery: | Twenty Days |
Weight: | 450kg | Encasement: | Wooden Case |
High Light: | automatic wrapping machine,flow wrap packaging machine |
Multi Function 304 Stainless steel starved feeding shut down PW - 300 E type packing machine for Disposable bag
Pricial capability and structural features:
1.Position stop function, noadhesive and no waste of membrane.
2.Compact strure, stable function and simple operation,All the controlling operates by the software, convenience for function adjustment and technical up grading.
3. Self-checking function, troubles can be read easily. Clean rotation system, more reliable operation and more convenient maintenance.
4. Dependant temperature PID controlling suitable for various materials of packaging membrane.High sensor photoelectric color charttracking, make the cutting position more correctly.
5. Double frequency converter controller, length of package will cutimmediately once setting, adjustment needless, saving time and film.
6.It adopts imported electric appliance, touch man-machine interface, convenient parameter setting.
7. The design of the connection structure between the equipment and the ground of the related plant should ensure that the facilities are not destroyed, the dead angle is easy to be cleaned and the maintenance is easy.
8. Control cabinet, control box, control button has good seal, can effectively prevent dust into it.
9. The pneumatic original is a famous brand product. The main module of PLC is Japanese Panasonic and Schneider famous brand products.
technical parameters:
Finished package size(mm) | Length | 40-500mm |
Width | 30-110mm | |
Height | 5-40mm | |
Vertical and cross sealing strength (Nuton/mm2) | 15N/m㎡ | |
Packaging speed (bag/minute) | 30-160Bags/min | |
Packaging film width(mm) | 80-450mm | |
Power specification | 220V 50/60Hz 3KVA | |
Machine weight (kilogram) | 800kg | |
Overall size (length * width * height) | 3780×640×1560mm |
the picture of packing:
