| Place of Origin: | china |
|---|---|
| Brand Name: | tengda |
| Certification: | CE |
| Model Number: | PW-300C |
| Minimum Order Quantity: | 1set |
| Price: | Negotiable |
| Packaging Details: | wood |
| Delivery Time: | 20days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50set/month |
| Finished Package Size: | 40-500/30-110/5-40mm | Packging Speed: | 5-230Bags/min |
|---|---|---|---|
| Power Specification: | 80-300mm | Machine: | 220V |
| Weight: | 800kg | Overall Size: | 3780×640×1560mm |
| High Light: | capsule blister packaging machine,pharmacy blister packaging machine |
||
Automatic blanking stainless steel silver pillow medicine blister packing machine
packing speed 5 - 230Bags / min
Automatic blanking Packaging machine uses color touch screen and stable and reliable high-precision dual-axis output PLC control, bagging, metering, filling, sealing, coding, cutting bag one-time completed.
It uses air circuit control and circuit control independent separation, low noise, stable performance.
Double-belt servo pull-die and dual-servo control, less resistance, bag molding is good, more beautiful, high-precision positioning, accurate size.
| Finished package size(mm) | Length | 40-500mm |
| Width | 30-110mm | |
| Height | 5-40mm | |
| Vertical and cross sealing strength (Nuton/mm2) | 15N／m㎡ | |
| Packaging speed (bag/minute) | 30-160Bags／min | |
| Packaging film width(mm) | 80-450mm | |
| Power specification | 220V 50／60Hz 3KVA | |
| Machine weight (kilogram) | 800kg | |
| Overall size (length * width * height) | 3780×640×1560mm | |
Pricial capability and structural features:
1. Using optical tracking technology, sealing and cutting position is accurate, cutting point tracking progress of up to ± 2mm. Digital input, the computer program to automatically adjust to set the length, without manual, reliable and stable bag length.
2. Sliding sealing mechanism, can be adjusted sealing (including horizontal and vertical seal) center height and width, fixed and reliable, to ensure long-term operation without displacement. Horizontal, vertical sealing speed continuously adjustable. Sealing width can be produced according to user needs.
3. Double synchronous belt pull film, controlled by the cylinder tension, automatic correction, automatic alarm protection, minimize loss
4. Self-checking function, troubles can be read easily.
5. High sensor photoelectric color charttracking, make the cutting position more correctly.
6. Dependant temperature PID controlling suitable for various materials of packaging membrane.
